After unveiling the Concept iX3 in April 2018, BMW has been hard at work developing the production version of the all-electric crossover. The Bavarian company has finally confirmed some of the technical details of the vehicle that is set to reach the assembly lines sometime in 2020 for the world market by the joint venture BMW Brilliance Automotive in Shenyang, China.
First and foremost, the production iX3 will use a 74-kWh battery pack which will ensure the zero-emission SUV can travel more than 273 miles (440 kilometers) at a single charge. Bear in mind that this number is measured by Europe’s WLTP cycle which means the EPA ratings will be slightly lower.
This Is It:
Gallery: BMW iX3 teasers
Power will be provided by BMW’s fifth-generation eDrive electric powertrain system and the automaker is proud to announce all powertrain components used for it were developed solely by the German manufacturer. The technology is scalable in terms of power and energy content and can thus be used in various different vehicle concepts and segments.
save over $3,400 on average off MSRP* on a new BMW X3
As far as the iX3’s output is concerned, BMW says it will deliver a peak power of 286 horsepower (210 kilowatts) and an instant torque of 295 pound-feet (400 Newton-meters). The power is generated by a single electric motor, which - contrary to previous reports - will drive the rear wheels only. We doubt there won’t be an all-wheel-drive variant but, at least for now, there’s no official word on it.
BMW is especially proud of the car’s low power consumption of less than 20 kWh per 62 miles (20 kWh per 100 kilometers) which allows for the use of a relatively compact battery pack.
With the launch of the all-electric iX3, the X3 will become the brand’s first model available both with conventional gasoline and diesel engines, as well as plug-in hybrid and purely electric drive.
Munich. The BMW iX3, the production of which will commence in 2020, facilitates locally emission-free driving in a novel and efficient form, whilst also being suitable for everyday use. A range of more than 440 km* within the legislative WLTP test cycle will be achieved with a net-battery size of 74 kWh*. The first purely electric Sports Activity Vehicle (SAV) is the trailblazer for BMW eDrive technology of the fifth generation, which, starting 2021, will also be deployed in the BMW i4 and the BMW iNEXT. For this purpose, both the drive system and the high-voltage battery unit featuring pioneering battery cell technology have been completely redeveloped. In the BMW iX3, the related advancement ensures brand-typical driving experience combined with outstanding efficiency and a novel balance of weight and range.
The BMW iX3 is yet a further milestone in the consistent realisation of the BMW Group’s electrification strategy. In 2020 the BMW X3 will become the brand’s first model available both with conventional petrol and diesel engines as well as plug-in hybrid and purely electric drive. With this “power of choice” offer, the globally operating company is taking into account the various different requirements and needs of their worldwide customers worldwide as well as maximum effectiveness in the reduction of CO2 emissions. The BMW iX3 is produced for the world market by the joint venture BMW Brilliance Automotive in Shenyang, China.
* = preliminary data
The fifth-generation BMW eDrive technology is the key to future-oriented sustainability for vehicles with electrified drive systems. It is the result of consistent development work within the framework of BMW EfficientDynamics and the experience gained by the BMW Group in the field of electric mobility spanning more than 10 years. All powertrain components used for BMW eDrive technology were developed solely by the BMW Group. Moreover, the electric motor and the high-voltage batteries are produced in corporately owned manufacturing facilities. In this way, the BMW Group ensures it has a decisive influence on the product properties and the quality of each component. Furthermore, the drive unit and the high-voltage battery unit are flexibly scalable in terms of power and energy content and can thus be used in various different vehicle concepts and segments.
EfficientDynamics at its best: New drive component with high efficiency and brand-typical power characteristics.
In the BMW iX3, EfficientDynamics reaches a new level. The vehicle’s fifth-generation BMW eDrive technology comprises a drive unit in which electric motor, system electronics and transmission are brought together into a central housing. As a result, the required installation space of the drive technology and its weight are considerably reduced. The ratio between motor output and weight of the drive system improves around 30 percent compared to the previous generation.
The electric motor featured in the BMW iX3 delivers a maximum power output of 210 kW/286 hp*. The torque of 400 Nm* allows for high initial acceleration and keeps a high level even at the upper motor speeds because of exclusive BMW design measures.
A further special feature of the electric motor being deployed in the BMW iX3 for the first time is a construction method that eliminates the need for rare earth materials.
The electric motor used in the BMW iX3 transfers power to the rear wheels. This effectuates a further increase in drive system efficiency. Moreover, the range of the BMW iX3 benefits from the drive design conveying the traditional BMW rear-wheel drive experience.
High-voltage batteries with significant higher energy density and responsible use of raw materials.
The high-voltage battery unit of the BMW iX3 is integral part of BMW’s fifth eDrive generation and is based on the latest evolution in NMC-811 technology in BMW typical prismatic design. The BMW Group has outstanding development capabilities in this field. This know-how flows into precise specifications with regard to the use of materials and battery design, according to which the battery cells are produced. Consistent research and development work not only raises energy density but also constantly improves all battery cell characteristics, in particular also durability and safety. In total, the BMW high-voltage battery shows the optimum of what is possible nowadays.
At the same time the BMW engineers were able to reduce the share of cobalt contained in the battery by another two thirds. Compared to former technology used by BMW Group, the gravimetric energy density on cell level in the BMW iX3 is around 20 percent higher.
With the BMW iX3 the raw materials Cobalt and Lithium for the first time are purchased by BMW directly and then handed over to the producer of the battery cells.
In addition, scalability and the compact design of the high-voltage battery unit have been further optimised. The battery cells are grouped into modules at specialised BMW production locations and finally assembled as high-voltage battery packs aligned to each model. The high-voltage battery unit in the BMW iX3 is installed in an extremely flat position in the vehicle floor. Thanks to this arrangement, there is no loss of space for passengers and the luggage compartment compared to the conventionally powered versions of the BMW X3.
Greater range thanks to high efficiency rather than a bigger battery
With a net energy content of 74 kWh*, the high-voltage battery unit installed in the BMW iX3 achieves a range of more than 440 km* in the legislative WLTP test cycle. Within its segment, the BMW iX3 boasts not only a unique low power consumption of less than 20 kWh/100km* accordingly to the WLTP test cycle, but also stands for a novel ratio between battery size and range.
Thanks to the favourable efficiency rating of the drive components and the high energy density of the high-voltage battery unit, the BMW iX3 achieves a range that is only possible for common electric vehicles with larger and thus heavier batteries.
Positive environmental impact secured.
The “real” ecological footprint of electric vehicles is sometimes questioned, particularly in markets still having a low percentage of green electricity in the public power grid. At the BMW Group every electrified model has to proof that for the entire cycle, comprising raw material procurement, supply chain, production and usage phase as well as recycling, its CO2 balance is substantially better than the one of a conventionally powered sibling. For the BMW iX3 the related advantage is more than 30 percent compared to a BMW X3 sDrive 20d when average European power supply is used during the car’s usage phase. If the vehicle is charged with green electricity the advantage is around 60 percent.
Furthermore, in analogy with the BMW i3 Plug&Play technology, the high-voltage battery featured in the BMW iX3 is planned for a second life as a stationary battery pack for the period following the first long life in the car. This way the already positive CO2 balance of the BMW iX3 can be further improved.
