Chevrolet Camaro SS

After a seven-year hiatus, the all-new 2010 Chevrolet Camaro SS is back in dealer showrooms. Two 6.2L V-8 engines are offered in the Camaro SS, including the new L99 on automatic-equipped vehicles and the LS3 on manual-equipped models. Both engines are derived from the LS3 that debuted on the 2008 Corvette. This 90-degree V-8 includes an aluminum block (with cast iron cylinder liners) and aluminum cylinder heads. The bottom end of the engine includes a new structural cast aluminum oil pan, with an oil capacity of 8.9 quarts (8.5 liters), while the two-valve cylinder head design is based on race-proven airflow dynamics. The intake valves measure 2.16 inches (55 mm) and exhaust valves are 1.60 inches (40.5 mm) in diameter.

Horsepower for the L99 is 400 (298 kW) at 5,900 rpm and torque is 410 lb.-ft. (556 Nm) at 4,300 rpm. The LS3 develops 426 horsepower (318 kW) and 420 lb.-ft. (569 Nm). Output on the L99 is lower than the LS3 because of a slightly lower compression ratio (10.4:1 vs. 10.7:1) and design features of the Active Fuel Management System. The L99 is paired exclusively with a six-speed automatic transmission.

The SS model’s new Tremec TR 6060 six-speed manual is designed to handle the high torque characteristics of the LS3 engine, while providing shorter throws, smoother gear synchronization and greater overall shift feel with little or no vibration. Its specs include a solid, 290-mm flywheel and single-plate clutch. The final drive ratio for LS3 vehicles is 3.45:1.

Fully independent front and rear suspensions are the underpinnings of the 2010 Camaro. The standard independent rear suspension is a first for Camaro and is designed to compete with the best in the world. It’s a 4.5-link system that includes a unique, L-shaped upper control arm that attaches to the knuckle at one end and incorporates a ride bushing in the rear.

Source: Chevrolet press
Photo Credits: Ron Dungca and Dylan von Kleist
